Dogbone RFID UHF Inlays from Virtualsphere Technologies combine a 97 × 27 mm PET antenna with the Impinj M730 chip for fast, dependable reads across supply chain and asset tracking. The wide antenna p…
₹18
Excl. 18% GST, added at checkout · per unit, minimum order 500
In Stock2000 units available
Dogbone RFID UHF Inlays from Virtualsphere Technologies combine a 97 × 27 mm PET antenna with the Impinj M730 chip for fast, dependable reads across supply chain and asset tracking. The wide antenna performs well on plastic, glass and cardboard, reaching up to 10 m with fixed readers and 5 m with handhelds. Each passive tag carries 128-bit EPC memory and complies with ISO/IEC 18000-63 EPC Gen 2, working across 860–960 MHz worldwide. Rated from -40 °C to +85 °C and resistant to moisture and solvents, it suits warehouses, sports timing and industrial automation. Custom encoding and printing are available.
Model: Dogbone RFID UHF Inlay
Dimensions: 97 mm × 27 mm
Material: PET
Tag type: Passive (no battery)
Chip: Impinj M730
EPC memory: 128 bits
Protocol: ISO/IEC 18000-63, EPCglobal Class 1 Gen 2
Frequency: 860–960 MHz (global UHF; covers ETSI 865–868 MHz and FCC 902–928 MHz)
Read range (fixed reader): Up to 10 m*
Read range (handheld reader: Up to 5 m*
Surface compatibility: Plastic, cardboard, glass and other non-metal surfaces
Operating temperature: -40 °C to +85 °C
Chemical resistance: Resistant to solvents and moisture
Sealing: IP65
Pre-encoding: Customer-specific EPC encoding
Applications: Asset tracking, warehouse management, sports timing, industrial automation, supply chain and logistics
*Read range depends on the reader, the antenna and the surface the tag is applied to.
